Siemens - 6ES7131-4BB01-0AB0
Siemens - 6ES7131-4BB01-0AB0
Regular price
€115,35 EUR
Regular price
Sale price
€115,35 EUR
Couldn't load pickup availability
Low stock: 9 left
SIMATIC DP 2DI DC 24V HF (5er Pack)
| Supply voltage | ||
| Rated value (DC) | 24 V; From power module | |
| Reverse polarity protection | Yes | |
| Input current | ||
| from supply voltage L+, max. | Dependent on encoder | |
| from backplane bus 3.3 V DC, max. | 10 mA | |
| Encoder supply | ||
| Type of output voltage | min. L+ (-0.5 V), under load | |
| Short-circuit protection | Yes; Electronic | |
| Output current | ||
| Rated value | 500 mA | |
| permissible range, lower limit | 0 mA | |
| permissible range, upper limit | 500 mA | |
| Power loss | ||
| Power loss, typ. | 0.4 W | |
| Address area | ||
| Address space per module | ||
| Address space per module, max. | 1 byte | |
| with packing | 2 bit | |
| Digital inputs | ||
| Number of digital inputs | 2 | |
| Input characteristic curve in accordance with IEC 61131, type 1 | Yes | |
| Input voltage | ||
| Type of input voltage | DC | |
| Rated value (DC) | 24 V | |
| for signal "0" | -30 to +5 V | |
| for signal "1" | +11 to +30V | |
| Input current | ||
| for signal "1", typ. | 8 mA | |
| Input delay (for rated value of input voltage) | ||
| for standard inputs | ||
| parameterizable | Yes; 0.1 / 0.5 / 3 / 15 ms | |
| at "0" to "1", min. | 0.05 / 0.4 / 2.7 / 14.85 | |
| at "0" to "1", max. | 0,15 / 0,6 / 3,3 / 15,15 | |
| at "1" to "0", min. | 0.05 / 0.4 / 2.7 / 14.85 | |
| at "1" to "0", max. | 0,15 / 0,6 / 3,3 / 15,15 | |
| Cable length | ||
| shielded, max. | 1 000 m | |
| unshielded, max. | 600 m | |
| Encoder | ||
| Connectable encoders | ||
| 2-wire sensor | Yes | |
| permissible quiescent current (2-wire sensor), max. | 1.5 mA | |
| Interrupts/diagnostics/status information | ||
| Diagnostics function | Yes | |
| Alarms | ||
| Hardware interrupt | Yes; Parameterizable | |
| Diagnoses | ||
| Short-circuit | Yes; Short-circuit of outputs to ground; module by module | |
| Diagnostics indication LED | ||
| Group error SF (red) | Yes | |
| Status indicator digital input (green) | Yes; per channel | |
| Parameter | ||
| Remark | 3 byte | |
| Diagnostics short-circuit | Disable / enable | |
| Potential separation | ||
| Potential separation digital inputs | ||
| between the channels | No | |
| between the channels and backplane bus | Yes | |
| Isolation | ||
| Isolation tested with | 500 V DC | |
| Dimensions | ||
| Width | 15 mm | |
| Height | 81 mm | |
| Depth | 52 mm | |
| Weights | ||
| Weight, approx. | 35 g | |
| Approvals / Certificates | ||
