Siemens - 6ES7134-4NB51-0AB0
Siemens - 6ES7134-4NB51-0AB0
Regular price
€215,01 EUR
Regular price
Sale price
€215,01 EUR
Couldn't load pickup availability
24 in stock
SIMATIC DP 2AI RTD HF
| General information | ||
| Product function | ||
| Isochronous mode | No | |
| Supply voltage | ||
| Load voltage L+ | ||
| Rated value (DC) | 24 V; From power module | |
| Reverse polarity protection | Yes | |
| Input current | ||
| from load voltage L+ (without load), max. | 30 mA | |
| from backplane bus 3.3 V DC, max. | 10 mA | |
| Power loss | ||
| Power loss, typ. | 0.6 W | |
| Address area | ||
| Address space per module | ||
| Address space per module, max. | 4 byte | |
| Analog inputs | ||
| Number of analog inputs | 2 | |
| permissible input voltage for voltage input (destruction limit), max. | 9 V | |
| Constant measurement current for resistance-type transmitter, typ. | 1.25 mA | |
| Cycle time (all channels) max. | Number of active channels per module x basic conversion time | |
| Technical unit for temperature measurement adjustable | Yes | |
| Input ranges (rated values), resistance thermometer | ||
| Cu 10 | Yes | |
| Input resistance (Cu 10) | 10 M¦ | |
| Ni 100 | Yes | |
| Input resistance (Ni 100) | 10 M¦ | |
| Ni 1000 | Yes | |
| Input resistance (Ni 1000) | 10 M¦ | |
| Ni 120 | Yes | |
| Input resistance (Ni 120) | 10 M¦ | |
| Ni 200 | Yes | |
| Input resistance (Ni 200) | 10 M¦ | |
| Ni 500 | Yes | |
| Input resistance (Ni 500) | 10 M¦ | |
| Pt 100 | Yes | |
| Input resistance (Pt 100) | 10 M¦ | |
| Pt 1000 | Yes | |
| Input resistance (Pt 1000) | 10 M¦ | |
| Pt 200 | Yes | |
| Input resistance (Pt 200) | 10 M¦ | |
| Pt 500 | Yes | |
| Input resistance (Pt 500) | 10 M¦ | |
| Input ranges (rated values), resistors | ||
| 0 to 150 ohms | Yes | |
| Input resistance (0 to 150 ohms) | 10 M¦ | |
| 0 to 300 ohms | Yes | |
| Input resistance (0 to 300 ohms) | 10 M¦ | |
| 0 to 600 ohms | Yes | |
| Input resistance (0 to 600 ohms) | 10 M¦ | |
| 0 to 3000 ohms | Yes | |
| Input resistance (0 to 3000 ohms) | 10 M¦ | |
| Thermocouple (TC) | ||
| Temperature compensation | ||
| internal temperature compensation | Yes | |
| Characteristic linearization | ||
| parameterizable | Yes; for Ptxxx, Nixxx | |
| for resistance thermometer | Ptxxx, Nixxx | |
| Cable length | ||
| shielded, max. | 200 m | |
| Analog value generation for the inputs | ||
| Measurement principle | integrating (Sigma-Delta) | |
| Integration and conversion time/resolution per channel | ||
| Resolution with overrange (bit including sign), max. | 16 bit; for Pt100, Ni100, Ni120, Pt200, Ni200, Pt500, Ni500, Pt1000, Ni1000, Cu10: 15 bit + sign; for 150, 300, 600, 3 000 ohms: 15 bit; for PTC: 1 bit | |
| Integration time (ms) | 16,7 / 20 ms | |
| Interference voltage suppression for interference frequency f1 in Hz | 50 / 60 Hz | |
| Conversion time (per channel) | Basic conversion time incl. integration time: 50 / 60 ms; additional conversion time for diagnostics of wire break test: 5 / 5 ms; additional conversion time for line compensation with 3-wire connection: 50 / 60 ms | |
| Smoothing of measured values | ||
| parameterizable | Yes; In four stages by means of digital filtering | |
| Step: None | Yes; 1x cycle time | |
| Step: low | Yes; 4x cycle time | |
| Step: Medium | Yes; 32x cycle time | |
| Step: High | Yes; 64x cycle time | |
| Encoder | ||
| Connection of signal encoders | ||
| for resistance measurement with two-wire connection | Yes | |
| for resistance measurement with three-wire connection | Yes; internal compensation of the line resistances | |
| for resistance measurement with four-wire connection | Yes | |
| Errors/accuracies | ||
| Operational error limit in overall temperature range | ||
| Resistance thermometer, relative to input range, (+/-) | Resistance-type transmitter: ±0.1 %; Pt100, Pt200, Pt500, Pt1000 standard: ±1.0 K; Pt100, Pt200, Pt500, Pt1000 climate: ±0.25 K; Ni100, Ni120, Ni200, Ni500, Ni1000 standard and climate: ±0.4 K; Cu10 ±1.5 K | |
| Basic error limit (operational limit at 25 °C) | ||
| Resistance thermometer, relative to input range, (+/-) | Resistance-type transmitter: ±0.05 %; Pt100, Pt200, Pt500, Pt1000 standard: ±0.6 K; Pt100, Pt200, Pt500, Pt1000 climate: ±0.13 K; Ni100, Ni120, Ni200, Ni500, Ni1000 standard and climate: ±0.2 K; Cu10 ±1 K | |
| Interrupts/diagnostics/status information | ||
| Diagnoses | ||
| Wire-break | Yes | |
| Group error | Yes | |
| Overflow/underflow | Yes | |
| Diagnostics indication LED | ||
| Group error SF (red) | Yes | |
| Parameter | ||
| Remark | 7 byte | |
| Diagnostics wire break | Disable / enable | |
| Group diagnostics | Disable / enable | |
| Overflow/underflow | Disable / enable | |
| Potential separation | ||
| Potential separation analog inputs | ||
| between the channels | No | |
| between the channels and backplane bus | Yes | |
| Between the channels and load voltage L+ | Yes | |
| Isolation | ||
| Isolation tested with | 500 V DC | |
| Dimensions | ||
| Width | 15 mm | |
| Height | 81 mm | |
| Depth | 52 mm | |
| Weights | ||
| Weight, approx. | 40 g | |
| Approvals / Certificates | ||
