Siemens - 6ES7135-4MB02-0AB0
Siemens - 6ES7135-4MB02-0AB0
Regular price
€210,02 EUR
Regular price
Sale price
€210,02 EUR
Couldn't load pickup availability
Low stock: 1 left
SIMATIC DP 2AO I HF
| General information | ||
| Product function | ||
| Isochronous mode | Yes | |
| Supply voltage | ||
| Load voltage L+ | ||
| Rated value (DC) | 24 V | |
| Reverse polarity protection | Yes | |
| Input current | ||
| from load voltage L+ (without load), max. | 80 mA | |
| from backplane bus 3.3 V DC, max. | 10 mA | |
| Power loss | ||
| Power loss, max. | 1.2 W | |
| Address area | ||
| Address space per module | ||
| Address space per module, max. | 4 byte | |
| Analog outputs | ||
| Number of analog outputs | 2 | |
| Current output, no-load voltage, max. | 18 V | |
| Cycle time (all channels) max. | 0.5 ms | |
| Output ranges, current | ||
| -20 mA to +20 mA | Yes | |
| 4 mA to 20 mA | Yes | |
| Connection of actuators | ||
| for current output two-wire connection | Yes | |
| for current output four-wire connection | No | |
| Load impedance (in rated range of output) | ||
| with current outputs, max. | 500 ¦ | |
| with current outputs, inductive load, max. | 1 mH | |
| Destruction limits against externally applied voltages and currents | ||
| Current, max. | 50 mA | |
| Cable length | ||
| shielded, max. | 200 m; 100 m if Twa < 2 ms | |
| Analog value generation for the outputs | ||
| Integration and conversion time/resolution per channel | ||
| Resolution with overrange (bit including sign), max. | 16 bit | |
| Settling time | ||
| for resistive load | 0.3 ms | |
| for capacitive load | 1 ms | |
| for inductive load | 0.5 ms | |
| Errors/accuracies | ||
| Operational error limit in overall temperature range | ||
| Current, relative to output range, (+/-) | 0.1 % | |
| Basic error limit (operational limit at 25 °C) | ||
| Current, relative to output range, (+/-) | 0.05 % | |
| Interrupts/diagnostics/status information | ||
| Substitute values connectable | Yes | |
| Diagnoses | ||
| Diagnostic information readable | Yes | |
| Wire-break | Yes | |
| Group error | Yes | |
| Diagnostics indication LED | ||
| Group error SF (red) | Yes | |
| Parameter | ||
| Remark | 7 byte | |
| Diagnostics wire break | Disable / enable | |
| Group diagnostics | Disable / enable | |
| Response to CPU/master STOP | Output current and de-energized/substitute a value/keep last value | |
| Potential separation | ||
| Potential separation analog outputs | ||
| between the channels | No | |
| between the channels and backplane bus | Yes | |
| Between the channels and load voltage L+ | Yes | |
| Isolation | ||
| Isolation tested with | 500 V DC | |
| Dimensions | ||
| Width | 15 mm | |
| Height | 81 mm | |
| Depth | 52 mm | |
| Weights | ||
| Weight, approx. | 40 g | |
| Approvals / Certificates | ||
