Siemens - 6ES7148-4FS00-0AB0
Siemens - 6ES7148-4FS00-0AB0
Regular price
€226,92 EUR
Regular price
Sale price
€226,92 EUR
Couldn't load pickup availability
Low stock: 2 left
SIMATIC DP F-Switch PROFIsafe
| Supply voltage | ||
| Rated value (DC) | 24 V | |
| power supply according to NEC Class 2 required | No | |
| Input current | ||
| from supply voltage 1L+, max. | 50 mA | |
| from load voltage 2L+ (without load), max. | 25 mA; Typical | |
| from backplane bus 3.3 V DC, max. | 40 mA | |
| Power loss | ||
| Power loss, typ. | 3 W | |
| Digital inputs | ||
| Number of digital inputs | 2 | |
| Input current | ||
| for signal "1", typ. | 3.5 mA | |
| Digital outputs | ||
| Number of digital outputs | 3 | |
| Short-circuit protection | Yes | |
| Total current of the outputs (per group) | ||
| all mounting positions | ||
| up to 55 °C, max. | 6 A | |
| Standards, approvals, certificates | ||
| Highest safety class achievable in safety mode | ||
| Performance level according to ISO 13849-1 | e | |
| SIL acc. to IEC 61508 | 3 | |
| Dimensions | ||
| Width | 45 mm | |
| Height | 130 mm | |
| Depth | 65 mm | |
| Approvals / Certificates | ||
