Siemens - 6ES7223-1BH22-0XA0
Siemens - 6ES7223-1BH22-0XA0
Regular price
€330,95 EUR
Regular price
Sale price
€330,95 EUR
Couldn't load pickup availability
Low stock: 1 left
SIMATIC S7-200 EM 223 8 DI DC 24V Sink/Source 8 DO DC 24V 0.75A/Channel source
| Supply voltage | ||
| Load voltage L+ | ||
| Rated value (DC) | 24 V | |
| permissible range, lower limit (DC) | 20.4 V | |
| permissible range, upper limit (DC) | 28.8 V | |
| Input current | ||
| from backplane bus 5 V DC, max. | 80 mA | |
| Power loss | ||
| Power loss, typ. | 3 W | |
| Digital inputs | ||
| Number of digital inputs | 8 | |
| Input voltage | ||
| Type of input voltage | DC | |
| Rated value (DC) | 24 V | |
| for signal "0" | 0 to 5 V | |
| for signal "1" | 15 V DC to 30 V DC | |
| Input current | ||
| for signal "1", typ. | 4 mA | |
| Input delay (for rated value of input voltage) | ||
| for standard inputs | ||
| at "0" to "1", max. | 4.5 ms | |
| Digital outputs | ||
| Number of digital outputs | 8 | |
| Short-circuit protection | No | |
| Limitation of inductive shutdown voltage to | L+ (-48 V) | |
| Output voltage | ||
| for signal "0", max. | 0.1 V | |
| for signal "1", min. | 20 V | |
| Output current | ||
| for signal "1" rated value | 750 mA | |
| Total current of the outputs (per group) | ||
| all mounting positions | ||
| Current per conductor/group, max. | 3 A | |
| Relay outputs | ||
| Switching capacity of contacts | ||
| with inductive load, max. | 0.75 A; each output | |
| on lamp load, max. | 5 W | |
| with resistive load, max. | 0.75 A; each output | |
| Cable length | ||
| shielded, max. | 500 m | |
| unshielded, max. | 150 m | |
| Encoder | ||
| Connectable encoders | ||
| 2-wire sensor | Yes | |
| permissible quiescent current (2-wire sensor), max. | 1 mA | |
| Potential separation | ||
| Potential separation digital inputs | ||
| Potential separation digital inputs | Yes; Optocoupler | |
| between the channels, in groups of | 4 | |
| Potential separation digital outputs | ||
| Potential separation digital outputs | Yes; Optocoupler | |
| between the channels, in groups of | 4 | |
| Isolation | ||
| Isolation tested with | 500 V AC | |
| connection method | ||
| Plug-in I/O terminals | Yes | |
| Dimensions | ||
| Width | 71.2 mm | |
| Height | 80 mm | |
| Depth | 62 mm | |
| Weights | ||
| Weight, approx. | 200 g | |
| Approvals / Certificates | ||
